Commander DPS
Can-Am Commander DPS
This NEW package adds Dynamic Power Steering to a great ride to give you even more value and comfort. And it includes our Visco-Lok QE front differential and cast-aluminum wheels. It’s also ideal for customizing with the added features that can truly make it yours.
https://www.youtube.com/watch?v=DWStv87L2q8&feature=player_embedded#t=0s
- ENGINE
-
- Type
- 976cc, V-twin, liquid-cooled, SOHC, 8-valve (4-valve/cyl)
- Bore & Stroke
- 91 x 75 mm
- Fuel System
- iTC™ with EFI and 54mm Throttle Body, 2 Siemens∞ VDO injectors
- Starting System
- Electric
- Transmission
- CVT, sub-transmission with high, low, park, neutral & reverse. Standard engine braking
- Drive Train
- Selectable 2WD/4WD shaft driven with Visco-Lok† front differential
- CHASSIS
-
- Frame
- Steel
- Cage type
- 2-inch diameter, high-strength steel, ROPS-approved
- Steering wheel adjustment
- Adjustable tilt steering
- Front Suspension Type/Shocks
- Double A-arm with dive-control geometry / Motion Control shocks
- Front Suspension Travel
- 10 in (254 mm)
- Rear Suspension Type/Shocks
- Torsional Trailing arm Independent (TTI) with external sway bar/ Motion Control shocks
- Rear Suspension Travel
- 10 in (254 mm)
- Front Brakes
- Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
- Rear Brake
- Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
- Tires/Front
- Carlisle∞ Black Rock 27 x 11 x 12 in (686 x 279 x 305 mm)
- Tires/Rear
- Carlisle∞ Black Rock 27 x 11 x 12 in (686 x 279 x 305 mm)
- Wheels
- Steel Black
- DIMENSIONS
-
- L x W x H (in)
- 118.3 x 58.6 x 72 in
- L x W x H (mm)
- 3,004 x 1,489 x 1,829 mm
- Wheelbase
- 75.8 in (1,924 mm)
- Ground Clearance
- 11 in (279 mm)
- Dry Weight
- 1,295 lb (585 kg)
- Towing Capacity
- 1,500 lb (680 kg)
- Cargo Box Capacity
- Total: 600 lb (272 kg) Upper: 400 lb (181 kg) Lower: 200 lb (91 kg)
- Cockpit Storage
- Glove Box: 4.5 gal (17.2 L) Under driver seat: 3,5 gal (13,1 L)
- Fuel Capacity
- 10 US gal (37.8 L)
- FEATURES
-
- Color(s) Available
- Yellow
- Instrumentation
- Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, sport mode, seat belt and 4x4 indicator, diagnostics, clock, auto shut off
- Anti-theft System
- Digitally Encoded Security System (D.E.S.S.™)
- Electrical
- Prewired for winch
- Lighting
- 4 60-watt projectors with tail lights/brake light
- DC Outlet
- Lighter type in console, standard connector in the back (15A)
- Warranty
-
- Basic
- 6 months limited factory warranty
- Extended
- B.E.S.T. available from 6 to 30 months
